High-Pressure Hoses 840 bar

High-pressure hoses designed for grease and centralized lubrication systems. Their multi-layer construction combines high pressure resistance with the flexibility required for industrial equipment and mobile machinery.

Test Pressure >840 bar at 20°C
Temperature −40 / +80°C operating temperature
Inner Tube PA6 thermoplastic polyamide
Outer Casing PU thermoplastic polyurethane
01 High pressure hose 840 bar technical design
Technical Design

High-Pressure Hose Construction

02 High pressure lubrication hose
Lubrication Technology

Flexible High-Pressure Line

Product Range

Item Numbers & Dimensions

High-pressure hoses are available in different dimensions, coil lengths and versions. Selected items are supplied pre-filled with NLGI class 2 grease, while other versions are supplied empty.

Item No. D D1 Grease m / coil Box Pallet
100-001 8,6 mm 4,0 mm NLGI class 2 50 m 250 m 3000 m
100-002 8,6 mm 4,0 mm empty 50 m 250 m 3000 m
100-002-250 8,6 mm 4,0 mm empty 250 m 250 m 3000 m
100-011 11,3 mm 6,3 mm NLGI class 2 50 m 200 m 2000 m
100-012 11,3 mm 6,3 mm empty 50 m 200 m 2000 m
100-011-1 11,3 mm 6,3 mm NLGI class 2 100 m 200 m 2000 m
100-012-1 11,3 mm 6,3 mm empty 100 m 200 m 2000 m
Engineering

Technical Information

High-pressure hoses in the 600–840 bar range are designed for grease and centralized lubrication systems.

The hose consists of an inner polyamide PA6 tube embedded in polyester reinforcement. A thermoplastic polyurethane outer casing protects the hose and contributes to its high mechanical strength.

The multi-layer construction provides high compressive strength while maintaining the flexibility required for installation on industrial machinery.

01
Inner Tube
Thermoplastic Polyamide 6 forms the internal lubricant-carrying tube.
02
Reinforcement
Polyester mesh provides reinforcement for high-pressure operation.
03
Casing
Thermoplastic polyurethane forms the protective outer casing.
Operating Temperature −40°C to +80°C For grease with corrosion protection additives: maximum +70°C.
Pressure Test >840 bar DIN EN ISO 1402, pressurisation 60 s, measured at 20°C.
Pressure at 60°C >460 bar High-pressure performance at elevated temperature.
Flexibility 20 / 45 mm Permissible bending radius depending on hose dimension at 20°C.
High pressure hose assembly
High-pressure hose assembly for centralized lubrication systems. Hose ends can be prepared with compatible screw sleeves and tube studs.
Dimensions

Sizes & Tolerances

The two principal hose dimensions cover DN4 and DN6 applications in centralized lubrication systems.

Parameter 100-001 / 100-002 100-011 / 100-012
Nominal size 4,0 × 8,6 mm 6,3 × 11,3 mm
Inner diameter 3,90 – 4,10 mm 6,2 – 6,5 mm
External diameter 8,50 – 8,75 mm 11,1 – 11,5 mm
Wall thickness eccentricity max. 0,40 mm max. 0,35 mm
Permissible bending radius at 20°C >20 mm >45 mm
Application

Designed for Lubrication Systems

High-pressure hoses can be used as main and secondary lubricant lines in automated centralized lubrication systems, as well as in manual lubrication applications.

01
Main Lines
From the pump element to the first distributor or main manifold.
02
Secondary Lines
Connections between the main distributor and downstream distributors.
03
Automatic Lubrication
Suitable for automated centralized grease lubrication systems.
04
Manual Lubrication
Flexible high-pressure connection for manual lubrication equipment.
SALPI — high-pressure components for professional centralized lubrication systems.
